Low Noise Differential Probes

Enquire Now
Download Catalogue

The Teledyne LeCroy low noise differential probe collection includes a diverse range of differential probes tailored for high-precision signal measurements. These probes span from low-bandwidth models like the ZD Series (up to 1.5 GHz) and ZD200 (200 MHz) for automotive and general-purpose use, to high-bandwidth options such as the DH Series (8-30 GHz) for PCIe and DDR systems. The WaveLink System (4-6 GHz) offers superior signal fidelity for high-speed DDR signals, while the AP033 Active Differential Probe excels in capturing high-speed differential signals with bandwidth up to 500 MHz. With various tips and compatibility across multiple devices, these probes address diverse testing needs across industries.

  • Precision Measurement: High bandwidth, low input capacitance, and superior CMRR ensure reliable signal acquisition.
  • Versatile Connectivity: Probes are compatible with Teledyne LeCroy oscilloscopes and other instruments via adapters.
  • Flexible Tips and Leads: Wide variety of probe tips including solder-in, browser, and high-temperature options.
  • Wide Application Range: Probes cater to automotive, high-speed DDR, PCIe testing, and RF measurements.
  • Ease of Use: Features like QuickLink architecture, ProBus interface, and auto-calibration enhance operational efficiency.
  • ZD Series Probes:
    • Bandwidth: 500 MHz to 1.5 GHz.
    • Input Capacitance: 1 pF.
    • Applications: Automotive, Serial Data, and power systems.
  • ZD200 Probe:
    • Bandwidth: 200 MHz.
    • Dynamic Range: ±20 V, Common Mode ±60 V.
  • DH Series Probes:
    • Bandwidth: 8 GHz to 30 GHz.
    • Signal Fidelity: High precision with automatic tip calibration.
  • WaveLink Differential Probe System:
    • Bandwidth: 4 GHz to 6 GHz.
    • Dynamic Range: Up to ±5 Vpk-pk.
    • Applications: DDR2, LPDDR2, DDR3 signals.
  • AP033 Active Differential Probe:
    • Bandwidth: DC to 500 MHz.
    • Input Capacitance: 1.6 pF differential, 3.1 pF to ground.
